2021 Matsuura MX-520 PC 4 5-Axis CNC Vertical Machining Center with 4 Station Pallet Changer ***Like New***
![Used 2021 Matsuura MX-520 PC 4 5-Axis CNC Vertical Machining Center with 4 Station Pallet Changer ***Like New***](https://i.machineryhost.com/894db62f7b7a6ed2f2a277dae56a017c/570f40292ff3b16a3524a1694747f71a/large-used-2021-matsuura-mx-520-pc-4-5-axis-cnc-vertical-machining-center-with-4-station-pallet-chang.jpg)
2021 Matsuura MX-520 PC 4 5-Axis CNC Vertical Machining Center with 4 Station Pallet Changer ***Like New***
orCall 213-393-6196
Description
Excellent Condition Low Hours
12,000 RPM
BT-40 Big Plus
Matsuura 4 Station Integrated Pallet Changer
Renishaw OMP 400 Probe
90 Station Tool Changer
Air Blow Swarf Removal
High Speed High Precision Five Axis Package
Nano Smoothing
24.8" X-Axis
22.04" Y-Axis
20.07" Z-Axis
-125~+10 Degree A-axis Rotation
360 Degree C-axis Rotation
φ11.81" Table Size
385LBS Max Pallet Capacity
20.47 x 12.9" Pallet Size
1,575IPM XYZ Traverse Rate
1,575IPM Feed Rate
8 Spare M Functions
Heidenhain Rotary Scales
Chip Conveyor
Specifications
Manufacturer | Matsuura |
Model | MX-520 PC 4 5-Axis CNC Vertical Machining Center with 4 Station Pallet Changer ***Like New*** |
Year | 2021 |
Condition | Used |
