2021 FANUC Robocut Alpha C 400 IC CNC Wire EDM 5-Axis

Sold

2021 FANUC Robocut Alpha C 400 IC CNC Wire EDM 5-Axis

Description

Excellent Condition Low Hours

Discharge Control Ai2

Anti-recast Power Supply

3D Coordinate System Rotation

Thermal Monitoring and Compensation

“Core Stitch” Slug Retention

Fully Integrated 4-axis and 5-axis for “Turn & Burn” Capability

Auto Wire Feeding AWF3

FANUC 31i-WB Controller with New iHMI User Interface

Wire Size: .004” to .012”

Inverter Controlled Chiller

CUT-LINKi Offline Cutting Monitor (STD)

Power Savings Mode

Rotary Glass Encoder

Twin Servo Automatic Wire Tension Control

Remote Jog Handle

28.7" x 24.8" x 10.0" Workpiece Dimensions

15.7" X-Axis Travel

11.8" Y-Axis Travel

10.0" Z-Axis Travel

1,100 Max Workpiece Weight

±2.362 U/V Travels

ø 0.004-0.012 Wire Diameter Capacity

66lbs Wire Capacity

145 Gallon Work Tank

Inverter Chiller

Digital Power Supply

Specifications

ManufacturerFANUC
ModelRobocut Alpha C 400 IC CNC Wire EDM 5-Axis
Year2021
ConditionUsed
